Ballroom Potent and Process Waste Lift Station for Bio Reactor

This Waste Lift Station was manufactured in 2022 for a major Biopharmaceutical factory site. It was installed above
ground in a cleanroom, all made from polished stainless steel and received process waste from a single use bioreactor.
It was pressurised to 1.5 bar and contains a pressure release valve Notably all instrumentation was part of the full
service package. This included Motors (with Motor Housings), Level Transmitters and Level Switches, an Internal Dip
Tube, a Pressure Indicator and various 1.5” – 2” Ferrule Nozzles connected to Ball Valves. This is a modular design to be
installed in a cleanroom and comes in a polished nish.
The tall frame at the rear allowed mounting of hose assembly and clamps forming single use air breaks.
This tank measured 1200mm x 1200mm x 900mm (36in x 48in x 48in) without the support frame and has a 1000 litre
(264 US Gallon) capacity
